Our premium quality conveyor belt fabric comes in a range of options and is used in a wide variety of applications.
Standout features include high adhesion levels between cover and plies, low elongation, a smooth finish and extreme resistance to abrasive materials. This results in greater field performance and service life.
Description
The cover compounds we have available have been specifically formulated to achieve high physical properties of abrasion, tear, cut and gouge resistance. We have 5 standard cover grades in natural and SBR (synthetic) rubber which are outlined in the table below. Specific cover grades are also available for applications such as heat, food and chemical resistance. Just ask one of our sales team for more information.
| Grade | Material | Properties |
| N Grade | Predominantly SBR rubber | Good all-purpose properties |
| M Grade | Natural rubber polymer | Excellent resistance to cut and tear |
| E Grade | Polymer blend | Specially compounded to have anti-static properties |
| SAR Grade | Polymer blend | Excellent abrasion resistance |
| XC Grade | Polymer blend | Superior resistance to cut and gouge |
Ply: belts can be manufactured in 2, 3 or 4 ply. 2 ply is generally used for light industrial environments such as recycling plants, 3 ply for light to medium applications such as mobile crushers and 4 ply for heavy industrial environments such as mining and brickwork.
Widths: our stocked widths range from 350mm up to 2400mm without longitudinal joints, but higher widths can be produced on request.
Cover Thicknesses: our stocked thicknesses range from 1.5mm to 21mm top cover and 1.5mm to 7mm bottom cover. Higher thicknesses can be produced on request.
Nb. Higher widths and cover thicknesses can be produced on request. 5 ply is also available on request.
