R-Line 40 Lining Rubber

Flexible Lining Rubber for Abrasion Protection

R-Line 40 Lining Rubber is a natural rubber lining material designed for wet and dry fine particle abrasion applications.

Balanced Wear Resistance and Flexibility

Its 40 Duro compound provides reliable abrasion resistance, strong flexibility, and secure bonding performance for industrial lining systems.

Reglin Product Supplied by SEC Business Group

Available in sheet, strip, lining panel, and custom fabricated formats for mining, quarrying, and mineral processing applications.

Description

Flexible Wear-Resistant Rubber Lining for Slurry & Abrasion Protection

R-Line 40 Lining Rubber is a high-quality 40 Duro natural rubber lining engineered for wet and dry fine particle abrasion in demanding industrial environments.

Manufactured from a highly elastic natural rubber compound, this lining provides an optimal balance of flexibility, durability, and wear resistance, making it ideal for protecting
steel equipment in mining, quarrying, and mineral processing applications.

The material features a pre-buffed backing to ensure reliable adhesion when bonded to steel or rubber surfaces using standard rubber adhesive systems.

Designed for Wet and Dry Abrasion Protection

SEC Business Group supplies durable lining solutions designed to extend equipment life and improve operational efficiency. R-Line 40 is ideal for applications requiring a balanced combination of flexibility, abrasion resistance, and secure bonding performance in slurry and dry material handling environments.

Features & Benefits

Premium natural rubber compound (NR).
Excellent resistance to wet and dry sliding abrasion.
Highly flexible and elastic for easy installation.
Good cut and tear resistance.
Resistant to mild chemicals including acids and alkalis.
Pre-buffed backing for enhanced bonding strength.
Compatible with Neoprene-based adhesives.
Designed for long-term wear protection.
Ideal for lining and abrasion control applications.
Available in sheets, strips, and custom-cut components.
Supplied by SEC Business Group.

Applications

Industrial Equipment Lining

Chutes
Tanks and pipework
Valves and pumps
Cyclones
Launders
Flotation cells
Sumps and underpans
Screen components
Trommels
Magnetic separator drums

General Wear Protection

Mill seals
Loading and discharge socks
Transfer and joining sleeves
Wear curtains
Sealing applications

Performance Advantages

Balanced abrasion resistance and flexibility.
Performs in both wet and dry material handling.
Easy bonding and installation with buffed back.
Reduces equipment wear and maintenance costs.

Technical Information

Property	Value	Standard
Polymer	NR
Colour	Pink with buffed back
Specific Gravity	1.05	ASTM D297
Hardness	40° ± 5° Shore A	ASTM D2240
Tensile Strength	17 MPa (min)	ASTM D412
Elongation @ Break	600% (min)	ASTM D412
Abrasion	130 mm³ (max) @ 5N	ASTM D5963
Temperature Range	-20°C to +70°C
Tear Strength	25 N/mm (min)	ASTM D624

Available Sizes

Part Number	Description	Weight (Per L/M)
REGBB40031500	3mm x 1500mm (10 L/M Rolls)	5.4 kgs
REGBB40061500	6mm x 1500mm (10 L/M Rolls)	10 kgs
REGBB40101500	10mm x 1500mm (10 L/M Rolls)	15.4 kgs
REGBB40121500	12mm x 1500mm (10 L/M Rolls)	19.6 kgs

Custom sizes, thicknesses, and fabricated components available on request.

Custom Options

R-Line 40 can be supplied as:

Equipment lining systems
Custom wear panels
Pipe and chute linings
Abrasion-resistant sealing components
Flexible protective curtains
Engineered lining solutions

Supply

This product is supplied by SEC Business Group.

For technical support, installation guidance, or custom fabrication, contact SEC Business Group.
